Datalogic Magellan 2300HS User Manual

Keyboard Model Cross Reference
Product Reference Guide 411
Table F-2. Scanset 1 Function Key Map
ASCII
(hex)
ASCII code Key Scancode
00 NUL ALT right Make E0h 38h
01 SOH ALT right Break E0h B8h
02 STX ALT left Make 38h
03 ETX ALT left Break B8h
04 EOT CTRL left Make 1Dh
05 ENQ CTRL left Break 9Dh
06 ACK CTRL right Make E0h 1Dh
07 BEL CTRL right Break E0h 9Dh
08 BS BS 0Eh
09 HT TAB right 0Fh
0A LF RIGHT arrow (inner keypad) 4Dh + E0
0B VT TAB left 0Fh + S
0C FF Enter (inner keypad) 1Ch + E0
0D CR CR 1Ch
0E SO INSERT (inner keypad) 52h + E0
0F SI PAGE UP (inner keypad) 49h + E0
10 DLE PAGE DOWN (inner keypad) 51h + E0
11 DC1 HOME (inner keypad) 47h + E0
12 DC2 LEFT arrow (inner keypad) 4Bh + E0
13 DC3 DOWN arrow (inner keypad) 50h + E0
14 DC4 UP arrow (inner keypad) 48h + E0

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
