Datalogic Magellan 2300HS User Manual

412 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Table F-3. Scanset 2 Function Key Map
ASCII
(hex)
ASCII code Key Scancode
00 NUL ALT right Make E0h 11h
01 SOH ALT right Break E0h F0h 11h
02 STX ALT left Make 11h
03 ETX ALT left Break F0h 11h
04 EOT CTRL left Make 14h
05 ENQ CTRL left Break F0h 14h
06 ACK CTRL right Make E0h 14h
07 BEL CTRL right Break E0h F0h 14h
08 BS BS 66h
09 HT TAB right 0Dh
0A LF RIGHT arrow (inner keypad) 74h + E0
0B VT TAB left 0Dh + S
0C FF Enter (right keypad) 5Ah + E0
0D CR CR 5Ah
0E SO INSERT (inner keypad) 70h + E0
0F SI PAGE UP (inner keypad) 7Dh + E0
10 DLE PAGE DOWN (inner keypad) 7Ah + E0
11 DC1 HOME (inner keypad) 6Ch + E0
12 DC2 LEFT arrow (inner keypad) 6Bh + E0
13 DC3 DOWN arrow (inner keypad) 72h + E0
14 DC4 UP arrow (inner keypad) 75h + E0
15 NAK F6 0Bh
16 SYN F1 05h
17 ETB F2 06h
18 CAN F3 04h
19 EM F4 0Ch
1A SUB F5 03h
1B ESC ESC 76h
1C FS F7 83h
1D GS F8 0Ah
1E RS F9 01h
1F US F10 09h

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
