Product Reference Guide 11-1
Chapter 11
Product
Specifications
Imager Product Specifications
Parameter Specification
Dimensions (Typical):
Height 7.5”/190 mm
Length 4.5”/115 mm
Width 3.0”/75 mm
Weight 11 ounces/312 g (without cable)
Aimer:
Illumination LEDs
Aiming LEDs
626nm +
30nm
526nm +
30nm
VGA, 640x480 or VGA, 752x480
Binary, TIFF, or JPEG output.
Skew Angle ±40 degrees
Pitch Angle ±40 degrees
Horizontal Velocity 2 inches (5 cm) per second
Scan Contrast
45% minimum for Matrix codes, 37.5% mini-
mum for all others
Voltage Requirements 4.5 - 14 VDC at imager
Operating Current
(Maximum)
Interlaced aiming mode : 470mA @5V
Concurrent aiming mode : 700 mA @5V
Standby Current
(Maximum)
Normal mode: 100 mA @5V
Low power mode : 55 mA @5V
