Symbologies
6-10 PowerScan
®
7000 2D
When Check Digit is set to Validate and Transmit, the imager only reads
Interleaved 2 of 5 bar codes printed with a check digit, and will transmit
this digit at the end of the scanned data. Default = No Check Digit.
Interleaved 2 of 5 Message Length
Scan the bar codes below to change the message length. Refer to Mes-
sage Length Description on page 6-2
for additional information. Mini-
mum and Maximum lengths = 2-80. Minimum Default = 4, Maximum
Default = 80.
Validate, but Don’t Transmit
* No Check Digit
Validate and Transmit
Minimum Message Length
Maximum Message Length
