Datalogic PowerScan 7000 2D - Telepen Message Length; Telepen Output

Symbologies
6-18 PowerScan
®
7000 2D
Telepen
Telepen Output
Using AIM Telepen Output, the imager reads symbols with start/stop
pattern 1 and decodes them as standard full ASCII (start/stop pattern 1).
When Original Telepen Output is selected, the imager reads symbols
with start/stop pattern 1 and decodes them as compressed numeric with
optional full ASCII (start/stop pattern 2). Default = AIM Telepen Out-
put.
Telepen Message Length
Scan the bar codes below to change the message length. Refer to Mes-
sage Length Description on page 6-2
for additional information. Mini-
mum and Maximum lengths = 1-60. Minimum Default = 1, Maximum
Default = 60.
On
* Off
Original Telepen Output
* AIM Telepen Output
Minimum Message Length
Maximum Message Length
