Datalogic PowerScan M8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
16-KEY DK MODEL PARAMETERS
Ì$-?Î
157
REPEAT TIMEOUT
Repeat Timeout allows the user to program an optional intercode delay (in msec.) between two
codes in a set of codes to be transmitted from scanner to host via Radio interface, when the
scanner is in quantity mode.
NOTE: Qty/Code Send Mode must be set to option 2 (code in CODE field is sent out for a
QTY number of times). See Qty/Code Send Mode on the previous page).
The number of codes depends on the unit inserted via keypad by the user, to cope with different
use cases. A minimum delay of 100 ms will be always present, the delay can be adjusted in
10ms increments.
Disable
set Repeat Timeout
 Read the above code.
 Select the length of the delay you want to set by scanning two barcodes (01 – 99) from the
Hex Numeric table in the back of this manual.
Example
: To program Repeat Timeout = 60ms
set Repeat Timeout Value Time (ms)
Read +
06
=
60ms


Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
