Datalogic PowerScan M8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
16-KEY DK MODEL PARAMETERS
Ì$-?Î
158
QTY/CODE SEPARATOR
This feature allows the insertion of a separator between QTY/CODE pairs.

Disable – no separator
define QTY/CODE separator
 Read the above code.
 Select the length of the separator you want to insert by scanning a barcode (1 – 8) from
the Hex Numeric table in the back of this manual.
 Define the separator string using a sequence of four hex ascii codes from the table at the
back of this manual.
Example
: To define QTY/CODE separator =
: (colon)
Define QTY/CODE
separator
length Hex codes Text string
Read +
1
+
20 + 20 + 3A + 20
=
space space
: space
For more information on this feature see “Message Formatting” starting in par. 6.1 and 6.2.


Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
