CHAPTER 2
SETUP
UNPACKING
Check carefully to ensure the reader and any cables or accessories ordered are present
and undamaged. If any damage occurred during shipment, contact "
Technical Support"
on page xii
.
SETTING UP THE QUICKSCAN™ QD2590 READER
Follow the steps provided in this section to connect and get your reader up and commu-
nicating with its host:
1. Connect the Interface Cable to the reader as shown in Figure 2. To disconnect the
cable, insert a paper clip or similar object into the opening shown.
2. Connect the other end to the Host (see the next section, "
Connect Host Interface"
on page 4 and Figure 3).
3. Modify "
Customizing Configuration Settings" on page 15 (only if modifications are
needed from factory settings).
