Datalogic QuickScan QD2590

COMMON READING CHARACTERISTICS
PRODUCT REFERENCE GUIDE 253
COMMON READING CHARACTERISTICS
Table 22 Reading Characteristics
DOF - DEPTH OF FIELD (TYPICAL)
A
,
B
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental light, 20°C, label inclination 10°
b. The values are obtained with the item "DOF Enhancement" enabled.
Symbology
DOF range
Code 39
5 mil: -0.5 - 25.0 cm (0.19" - 9.8")
10 mil: 0.5 - 38 cm (0.19" - 14.9")
EAN13 13 mil: 0.5 - 41.0 cm (0.19" - 16.1")
PDF417 6.7 mil: 0.5 - 21.0 cm (0.19" - 8.3")
Datamatrix 10 mil: 0.5- 21.5 cm (0.19" - 8.5")
Code 128 5 mil: 2 - 21.5 cm (0.8" - 8.5")
QR Code 20 mil: 0- 37 cm (0" - 14.6")
Max Resolution
1D Min = 3 mil
PDF417 Min = 3 mil
Datamatrix Min = 5 mil
