Datalogic QuickScan QD2590 User Manual

INTERFACE SELECTION
PRODUCT REFERENCE GUIDE 11
INTERFACE SELECTION
Upon completing the physical connection between the reader and its host, proceed
directly to "
Configuring the Interface" on page 11 for information and programming for
the interface type the reader is connected to (for example: RS-232, Keyboard
Wedge,USB, etc.) and scan the appropriate bar code in that section to select your sys-
tem’s correct interface type.
The reader, depending upon the model, will support one of the following sets of host
interfaces:
• USB (Keyboard, COM, OEM)
• USB Composite (Keyboard + COM)
•USB HID POS
• USB Toshiba TEC
• RS-232 STD
• RS-232 WN
• RS232 OPOS
• Keyboard WedgeIBM46XX port 9b (a specific cable is required)
• Datalogic Magellan
Scanners' specific interface
CONFIGURING THE INTERFACE
Scan the programming bar code from the following section which selects the appropri-
ate interface type to match the system the reader will be connected to. Next, proceed to
the corresponding chapter in this manual (also listed in the table) to configure any
desired settings and features associated with that interface.
NOTE: Unlike some other programming features and options, interface
selections require that you scan only one programming bar code label. DO
NOT scan an ENTER/EXIT bar code prior to scanning an interface selection
bar code. Some interfaces require the reader to start in the disabled state
when powered up. If additional reader configuration is desired while in this
state, pull the trigger and hold for 5 seconds. The reader will change to a
state that allows programming with bar codes.

Datalogic QuickScan QD2590 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Scanner resolution	0.17 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	CPC Binary, Codabar, Codabar 125, Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 25 (IR 2 of 5), Code 25 (non-IR 2 of 5), Code 3 of 9, Code 32, Code 39, Code 93, DUN 14, DataBar14, Discrete 2 of 5, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, Facing Identification Mark, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, GS1-128 (UCC/EAN-128), HIBC, IATA, ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Intelligent Mail, Interleaved 2 of 5, JAN, Latent image, MSI, Matrix 2 of 5, PDF417, PLANET, POSTNET, Pharmacode, Plessey, PostBar, RM4SCC / KIX, S-Code, Telepen, Trioptic, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, QR Code
Cable length	2 m
Standard interfaces	USB
Connectivity technology	Wired
Product color	Black
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	450 mA
Cables included	USB Type-C
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Material	Polyvinyl chloride (PVC)
Connector 1	USB C
Product type	USB cable
Connector gender	Male/Male
Brand compatibility	Datalogic
Connector 1 form factor	Straight
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	126 mm
Width	148 mm
Height	68 mm
Weight	145 g
