238 QUICKSCAN™ QD2590
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can be one of hex
0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous
to or following the transmitted bar code data depending upon how this option is
enabled. This feature provides options for configuring custom Label IDs as a pre-loaded
set or individually per symbology (see "
Label ID: Set Individually Per Symbology" on page
72). If you wish to program the reader to always include an industry standard label iden-
tifier for ALL symbology types, see "
Global AIM ID" on page 70.
Label ID: Pre-loaded Sets
The following table lists the pre-loaded label ID sets for the USA and Europe.
Table 12 - Label ID Pre-loaded Sets
SYMBOLOGY USA LABEL ID SET EU LABEL ID SET
ASCII
character
Hex
value
ASCII
character
Hexadecimal
value
ABC Codabar S 530000 S 530000
CODABAR % 250000 R 520000
Code 39 CIP HR Y 590000 Y 590000
Code 93 & 260000 U 550000
Code 11 CE 434500 b 620000
Code 128 # 230000 T 540000
Code 32 A 410000 X 580000
Code 39 * 2A0000 V 560000
Datalogic 2of5 s 730000 s 730000
EAN13 F 460000 B 420000
EAN13 P2 F 460000 L 4C0000
EAN13 P5 F 460000 M 4D0000
EAN8 FF 464600 A 410000
EAN8 P2 FF 464600 J 4A0000
EAN8 P5 FF 464600 K 4B0000
FOLLETT 2OF5 O 4F0000 O 4F0000
GS1 DATABAR EXPANDED
RX 525800 t 740000
GS1 DATABAR LIMITED
RL 524C00 v 760000
GS1 DATABAR OMNIDIRECTIONAL
R4 523400 u 750000
GS1-128 000000 k 6B0000
I2OF5 i 690000 N 4E0000
IATA IA 494100 & 260000
Industrial 2 of 5 W 570000 W 570000
Interleaved 2 of 5 e 650000 e 650000
ISBN l 490000 @ 400000
ISBT128 f 660000 f 660000

Datalogic QuickScan QD2590 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Scanner resolution	0.17 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	CPC Binary, Codabar, Codabar 125, Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 25 (IR 2 of 5), Code 25 (non-IR 2 of 5), Code 3 of 9, Code 32, Code 39, Code 93, DUN 14, DataBar14, Discrete 2 of 5, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, Facing Identification Mark, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, GS1-128 (UCC/EAN-128), HIBC, IATA, ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Intelligent Mail, Interleaved 2 of 5, JAN, Latent image, MSI, Matrix 2 of 5, PDF417, PLANET, POSTNET, Pharmacode, Plessey, PostBar, RM4SCC / KIX, S-Code, Telepen, Trioptic, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, QR Code
Cable length	2 m
Standard interfaces	USB
Connectivity technology	Wired
Product color	Black
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	450 mA
Cables included	USB Type-C
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Material	Polyvinyl chloride (PVC)
Connector 1	USB C
Product type	USB cable
Connector gender	Male/Male
Brand compatibility	Datalogic
Connector 1 form factor	Straight
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	126 mm
Width	148 mm
Height	68 mm
Weight	145 g
