Bluetooth Features
7-6 QuickScan
®
QS6500/QS6500BT
Bluetooth Connectivity Mode
The feature allows the imager to be linked to any Bluetooth (BT)
enabled device which can accept such a connection with other devices.
To implement this mode, follow these instructions:
1. Place the imager in Programming Mode by scanning the START
bar code.
2. Scan the “Connect to a BT Device” bar code to put the imager in
the mode enabling a link to a device other than its own Base Sta-
tion.
3. Scan the END bar code to exit Programming Mode.
4. Scan the “Begin Pin” bar code.
5. Set the four- to six-character PIN code assigned to the target Blue-
tooth device using the bar codes available in
Appendix B, Alpha-
Numeric Pad.
6. Scan the “End Pin” bar code.
7. Use the software that drives the other BT device to scan for devices
in the area. The QS6500BT imager will be displayed as "Data-
logic
1
handheld scanner." Each BT device uses different methods
to link, so you’ll need to follow the instructions for the device
being connected to.
1. Depending upon when your scanner was purchased, the display might read “PSC hand-
held scanner.”
NOTE
The Serial Peripheral Protocol is the only inter-
face supported.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
