Product Reference Guide C-1
Appendix C
Keyboard Function
Key Mappings
Keyboard Model Cross Reference
Ta bl e C- 2 summarizes the keyboard models, their defined protocol,
scancode set, and some unique features. The remaining tables in this
chapter provide the function key maps associated with each of the scan-
code sets.
Table C-1. USB Function Key Usage Map
ASCII Key value Usage Name
Modifier/
Scancode
00 NUL ALT right Make 40h 00h
01 SOH ALT right Break
00h 00h
1
02 STX F11 00h 44h
03 ETX F12 00h 45h
04 EOT GUI right Make 80h 00h
05 ENQ GUI right Break
00h 00h
1
06 ACK CTRL right Make 10h 00h
07 BEL CTRL right Break
00h 00h
1
08 BS BS 00h 2Ah
09 HT TAB right 00h 2Bh
0A LF RIGHT arrow (inner keypad) 00h 4Fh
0B VT TAB left 02h 2Bh
0C FF Enter (right keypad) 00h 58h
0D CR CR 00h 28h
0E SO INSERT (inner keypad) 00h 49h
0F SI PAGE UP (inner keypad) 00h 4Bh
10 DLE PAGE DOWN (inner keypad) 00h 4Eh
11 DC1 HOME (inner keypad) 00h 4Ah
12 DC2 LEFT arrow (inner keypad) 00h 50h

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
