Datalogic QuickScan QS6500 User Manual

Symbologies
6-4 QuickScan
®
QS6500/QS6500 BT
UPC-A — continued
Truncate Leading/Ending
The leading or ending digits of bar code data characters can be trun-
cated. Select from 00 (no truncation) to 15.
NOTE
The imager will beep instead of reading anything when
the truncate value is more than the bar code data digits
or the truncate leading value overlaps the truncate end-
ing value.
START
MODE BARCODE
Sets from 00 to 15 characters to truncate from either the leading or
ending characters of scanned bar code data. To configure this fea-
ture, scan the “START” bar code above to place the unit in Program-
ming Mode, then the SET TRUNCATION: LEADING or SET
TRUNCATION: ENDING, followed by the digits from the Alphanu-
meric table in
Appendix B, Alpha-Numeric Pad representing the
desired quantity of digits to trumcate from the message string. Accept
your selection by scanning the “SET” bar code below and finally, exit
programming mode by scanning the “END” barcode below.
DEFAULT SETTING FOR THIS FEATURE: 00 (None)
Set Truncation:
Leading
Set Truncation:
Ending
SET
END

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
