Datalogic QuickScan QS6500 User Manual

Product Reference Guide F-1
Chapter F
LED & Beeper Indications
Bluetooth models offer a special set of LED and Beeper indications
beyond the simple “Good Read” and error signals provided by corded
models. These indications allow you to understand a variety of functions
and features implemented for the product.
Bluetooth Imager Indications
STATUS
GREEN
LED
RED
LED
ORANGE
LED
BEEPER
Connected or re-enter
into the boundary (When
scanner is sleeping)
Blink
once
Special beep
Disconnected or Out of
boundary (When scan-
ner is sleeping)
Blink
twice
Disconnected or Out of
boundary (Trigger is
pressed only)
Blinks
Hardware fail Flash
Program download Flash
Program checksum fail Flash
Scan disable (Trigger is
pressed only)
Blink Special beep
Data transmitting ON
High freq.beep
for 300msec
Data transmission Fail
ON for
Xmsec

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
