Global Features
Product Reference Guide 3-17
Global Maximum Code Length
Global maximum length can be set to qualify data entry. The length is
defined as the actual bar code data length to be sent. bar code labels with
lengths exceeding these limits will be rejected. Ensure that the mini-
mum-length setting is no greater than the maximum-length setting; oth-
erwise, the labels of the symbology will not be readable. In particular,
you can set the same value for both minimum and maximum lengths to
force decoding of only fixed-length bar codes. This setting has no effect
on certain symbologies of fixed length.
START
MODE BARCODE
Global Maximum length can be set from 0 to 255. To
set this feature, scan the “START” bar code above to
place the unit in Programming Mode, then the “Set
Global Maximum Length,” followed by the digits from
the Alphanumeric table in
Appendix B, Alpha-
Numeric Pad representing your desired maximum
length. Accept your selection by scanning the “SET”
bar code below and finally, exit programming mode by
scanning the “END” barcode below.
DEFAULT SETTING FOR THIS FEATURE: 64
Set Global
Maximum
Length
SET
END
³
.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
