Datalogic QuickScan QS6500 User Manual

Interface Related Features
4-2 QuickScan
®
QS6500/QS6500 BT
Table 4-1. Interfaces Supported
RS-232 Page Keyboard Wedge Page
RS-232 Standard
4-9
Keyboard Wedge I
a
4-27
RS-232 Wincor-Nixdorf
4-9
Keyboard Wedge J
a
4-27
IBM
Keyboard Wedge K
a
4-27
IBM 4683 Port 5B
4-25
Keyboard Wedge L
a
4-27
IBM 4683 Port 9B
4-25
Keyboard Wedge M
a
4-27
IBM 4683 Port 17
4-25
Keyboard Wedge N
a
4-27
USB
Keyboard Wedge O
a
4-27
IBM USB
4-25
Keyboard Wedge P
a
4-27
USB Keyboard
4-25
Keyboard Wedge Q
a
4-27
Keyboard Wedge
Keyboard Wedge R
a
4-27
Keyboard Wedge A
a
a. Consult Table 4-2 for more information regarding keyboard wedge inter-
face types.
4-27
Keyboard Wedge S
a
4-27
Keyboard Wedge B
a
4-27
Keyboard Wedge T
a
4-27
Keyboard Wedge C
a
4-27
Keyboard Wedge U
a
4-27
Keyboard Wedge D
a
4-27
Keyboard Wedge V
a
4-27
Keyboard Wedge E
a
4-27
Keyboard Wedge W
a
4-27
Keyboard Wedge F
a
4-27
Keyboard Wedge X
a
4-27
Keyboard Wedge G
a
4-27
Keyboard Wedge Y
a
4-27
Keyboard Wedge H
a
4-27 Wand Emulation
4-34
NOTE
The correct interface cable is included for the imager
interface type you ordered.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
