AP20 Installation and Operating Guide Page 50
AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25
Home (Main)
Menu (System)
Channel Profile Setup
Current Channel
Profile (Select)
Edit Profiles
Copy Profile
Copy Default to Profile
Rename Profile
Delete Profile
Channel Names (1-16)
Channel Names (Assign)
Vu Meter (On/Off)
Routing /
Crossovers
Formats
Output Channel Routing
High / Low Pass Filters
Crossover ID
Output Channel Trim
Channel mapping chart
Global Delay and Surround Offset (set)
Global audio delay for current format (ms)
Surround Delay (ms)
H. I. Delay (ms)
Format Trim (dB)
Surround Offset (dB)
Fade In (ms)
Fade Out (ms)
Extended Surround Options
None
Copy surround chs to rear surround chs
Matrix Decode Surround Channels
Signal mapping diagram
Format Options
Channel Profile
Channel Delays (mS)
Input ch select (1-8, 9-16)
Output ch select (1-8, 9-16)
Film Options
Digital Cinema Format Options
DC Audio Configura ion (select)
5.1 DCP
7.1 DCP
5.1 DCP to 7.1 speakers
ES Matrix
Matrix
DCP includes HI (on/off)
DCP includes VI (on/off)
Signal mapping diagram
Film Optical Audio Type:
None
Mono
A-Type
SR
Matrix Decoder
(On/Off)
Optical Bass
Extension (On/Off)
Film Setup
Bass Enh
Notes:
The Format Options available are determined by which Input Source has been selected:
Format Option
Input Source(s)
Global Delay & Surround Offset All
Nonsync Level & Routing Nonsync 1 or 2
Extended Surround Options Analog 8ch, Nonsync 1 or 2, Mic Pre, Digital ch 9-16, Op ical
Mic Level & Routing Mic Pre
Film Options Optical (Also requires that H338 Optical Film Card is installed)
Matrix & Routing Digital ch 1-8, Digital ch 1-16
Digital Cinema Format Options Digital ch 1-8, Digital ch 1-16
Decoder Setup Digital ch 1/2, Digital ch 9/10, TosLink A or B, S/PDIF Coax, HDMI 1-4
1
Decoder Setup
Speaker Configuration (select 5.1 or 7.1)
Phantom Center (on/off)
DTS Neo:6 Option (select)
Off
Music
Cinema
Misc Options (select)
Direct Mode (decoder disabled)
Disable Surround Remap
DTS LFE +10dB
Nonsync Level and Routing
Nonsync Gain (set)
L (dB)
R (dB)
Select:
Screen chs (L/R)
Surround chs (Ls/Rs)
Screen & surround chs
Matrix Decoder
Enable Bass Enh
(see Bass Enh)
Enable Mic (see mic level & routing)
Mic Level and Routing
Gain (set) (dB)
Select:
Screen Center
Screen chs
Surround chs
Screen & surround
AP20 Menu Structure
Software V1.04 00 and above
(Page 3)
See page 4
See page 4
1
2. Input channels 7/8 are routed to 9/10 if a) copy surrounds to rear surrounds is set, and b) input source is 8 channel analog or 8 channel digital 1-8.
Matrix and Routing
Enable Matrix Decoder
Enable Bass Enhancement
