AP20 Menu Structure
Software V1.04.00 and above
(Page 4)
Film Setup
Azimuth
Mute
Proj 1/2 (select)
Graph image
Digital Soundtrack
Input
Slit Loss EQ
Graph image
Optical Gain Mute
Auto Adjust
Proj 1/2 (select)
Left/Right
(manual adjust)
Mute
Proj 1/2 (select)
Left/Right (select)
Left/Right
(manual adjust)
Parametric Filter Setting
Freq (Hz)
Q
Gain (dB)
Select Input for Digital
Soundtrack:
None
Digital Chs. 1-8
Analog Chs. 1-8
Mute
Bass Enh
Matrix Bass Extension
Pink Noise Enable (select)
Center
LFE
Set Parameters for Bass Extension
Gain (dB)
Low pass Filter (Hz)
