12 Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006
5.1 WARNINGS
Warnings are non-critical alarm conditions and do not affect the operation of the generator system, they
serve to draw the operators attention to an undesirable condition.
In the event of a warning alarm the LCD will display:-
BATTERY CHARGE FAILURE, if the module does not detect a voltage from the warning light terminal on
the auxiliary charge alternator the
icon will illuminate.
FAIL TO STOP, If the module detects the engine is still running when the ‘Fail to stop timer’ expires, then
the module will display:-
NOTE:- ‘Fail to Stop’ could indicate a faulty oil pressure sender - If engine is at rest check oil
sender wiring and configuration.
AUXILIARY INPUTS, if an auxiliary input has been configured as a warning the appropriate LCD
segment will be displayed:-
!
