34 Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006
11.1.4 PLUG “G” 5 WAY
PIN No DESCRIPTION CABLE SIZE NOTES
39 CT Secondary for L1 2.5mm² (13 AWG) Connect to secondary of L1 monitoring
CT
40 CT Secondary for L2 2.5mm² (13 AWG) Connect to secondary of L2 monitoring
CT
41 CT Secondary for L3 2.5mm² (13 AWG) Connect to secondary of L3 monitoring
CT
42 CT secondary common 2.5mm² (13 AWG) Connect to secondary of all monitoring
CT’s
43 Not connected -
11.1.5 PLUG “H” 4 WAY
PIN No DESCRIPTION CABLE SIZE NOTES
44 Oil Pressure Input 0.5mm² (20 AWG) Connect to Oil pressure sender
45 Coolant Temperature
Input
0.5mm² (20 AWG) Connect to Coolant Temperature sender
46 Not connected -
47 Sender Common Return 0.5mm² (20 AWG) Return feed for senders*.
NOTE*:- If using single terminal senders refer to connection diagram. If using earth return
type senders connect return terminals to pin 47 and also connect pin 47 to earth. This is detailed
in the Appendix section entitled “Sender wiring recommendations” elsewhere in this manual.
