30 Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006
9.8 CONFIGURABLE INPUTS
Factory default settings are in bold italicised text.
Parameter Selection
33 – Input 1 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 -Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Remote Start, close to activate
9 - Remote Start, open to activate
34 – Input 2
0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Electrical trip, close to activate
9 - Electrical trip, open to activate
35 – Input 3 0 - Warning, Delayed, close to activate
1 - Warning, Delayed, open to activate
2 - Warning, Immediate, close to activate
3 - Warning, Immediate, open to activate
4 - Shutdown, Delayed, close to activate
5 - Shutdown, Delayed, open to activate
6 - Shutdown, Immediate, close to activate
7 - Immediate, Shutdown, open to activate
8 - Lamp test, close to activate
9 - Lamp test, open to activate
36 – Input 4 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
37 - Input 5 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Oil pressure switch, Shutdown, open for low oil pressure
9 - Oil pressure switch, Shutdown, close for low oil pressure
