DSE Model 5110 Automatic Start Engine Management Instrumentation System
Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006 41
16 FACTORY DEFAULT SETTINGS
Modules are shipped from the factory with parameters set to the following values. These can be user
adjusted via the front panel configuration editor. For further details on adjustment via the front panel
editor, see the section entitled “Front panel configuration” elsewhere within this manual.
Parameter Default
0 - Start delay 5s
1 - Preheat 0s
2 - Crank attempt 10s
3 - Crank rest 10s
4 - Safety delay 8s
5 - Warming up 0s
6 - Return delay 30s
7 - Cooling run 60s
8 - E.T.S. solenoid hold 0s
9 -Sensor fail delay 2s
10 – Fail to Stop Delay 60s
11 - Low Oil Pressure 15PSI
12 - High Temperature 95°C
13 - Under Speed 1250RPM
14 - Over Speed 1750RPM
15 - Underfrequency 40Hz
16 - Overfrequency 57Hz
17 - Charge Alt Failure 8V DC
18 - Flywheel teeth 0 (magnetic pickup disabled)
19 - CT Primary 500A
20 - Alternator poles 4
21 - Oil Pressure transducer 3 - VDO 0-10bar
22 - Coolant temp transducer
2 - VDO 0-120°C
23 - Fast loading enabled 0 - No
24 - AC system 3 - 3 phase 4 wire
25 - Oil pressure display units 0 - Bar/PSI
26 - Out
ut 4 active
32 - LCD 4 12 - Auxiliary input 5 active
33 - Input 1 8 - Remote Start, close to activate
34 - Input 2 0 - Delayed, Warning, close to activate
35 - Input 3 2 - Warning, Immediate, close to activate
36 - Input 4 4 - Delayed, Shutdown, close to activate
37 - Input 5 6 - Immediate, Shutdown, close to activate
