36 Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006
11.2.3 PLUG “F” 4 WAY
PIN
No
DESCRIPTION
35 Generator L1 sensing input. Connect to alternator L1 output.
36 Generator L2 sensing input. Connect to alternator L2 output. If using single phase only do not
connect this terminal.
37 Generator L3 sensing input. Connect to alternator L3 output. If using single phase only do not
connect this terminal.
38 Generator N sensing input. Connect to alternator N output.
11.2.4 PLUG “G” 5 WAY
PIN No DESCRIPTION
39 Generator L1 current transformer connection.
40 Generator L2 current transformer connection. If single phase is used do not connect this pin.
41 Generator L3 current transformer connection. If single phase is used do not connect this pin.
42 Generator current transformer common connection and CT earth connection.
43 Not used. Do not connect to this terminal.
11.2.5 PLUG “H” 4 WAY
PIN
No
DESCRIPTION
44 Oil Pressure sensing input. Connect to resistive type oil pressure sender. Refer to connection
diagram for details.
45 Coolant Temperature sensing input. Connect to resistive type coolant temperature sender. Refer
to connection diagram for details.
46 Not used. Do not connect to this terminal.
47 Sender Common connection. Return feed from sender units - refer to connection diagram for
details.
11.2.6 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part numbers
below.
5110 Terminal Connector Plug description DSE Part number
1-8 A BL08 8way 5.08mm spacing connector plug 007-125
9-19 B BL11 11way 5.08mm spacing connector plug 007-135
35-38 F BL04 4way 10.16mm spacing connector plug 007-003
39-43 G BL05 5way 5.08mm spacing connector plug 007-329
44-47 H BL04 4way 5.08mm spacing connector plug 007-100
NOTE:- Connectors C, D & E are not fitted to the 5110 remote start module.
