54 Part No. 057-009 5110 Operating Manual Issue 3.3 3/1/2006
CONFIGURABLE INPUTS
Factory default settings are in bold italicised text.
Parameter Selection
31 – Input 1 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 -Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Remote Start, close to activate
9 - Remote Start, open to activate
32 – Input 2 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Electrical trip, close to activate
9 - Electrical trip, open to activate
33 – Input 3 0 - Warning, Delayed, close to activate
1 - Warning, Delayed, open to activate
2 - Warning, Immediate, close to activate
3 - Warning, Immediate, open to activate
4 - Shutdown, Delayed, close to activate
5 - Shutdown, Delayed, open to activate
6 - Shutdown, Immediate, close to activate
7 - Immediate, Shutdown, open to activate
8 - Lamp test, close to activate
9 - Lamp test, open to activate
34 – Input 4 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
35 - Input 5 0 - Delayed, Warning, close to activate
1 - Delayed, Warning, open to activate
2 - Immediate, Warning, close to activate
3 - Immediate, Warning, open to activate
4 - Delayed, Shutdown, close to activate
5 - Delayed, Shutdown, open to activate
6 - Immediate, Shutdown, close to activate
7 - Immediate, Shutdown, open to activate
8 - Oil pressure switch, Shutdown, open for low oil pressure
9 - Oil pressure switch, Shutdown, close for low oil pressure
NOTE:- This section details the configuration editor of the “new” 5110 module. To identify the “original” and
“new” controllers, See the section entitled Identification of “original” 5110 and “new” 5110 elsewhere in this manual.
NOTE:- This page contains configuration details for the “new” V3 5110 only ! For details of the “new”(V4) 5110 and
“original” 5110 see the Front Panel configuration section elsewhere in this manual
