DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
16 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
OVERSPEED, if the engine speed exceeds the pre-set trip a shutdown is initiated. Alarm Shutdown Overspeed will
be displayed. Overspeed is not delayed, it is an immediate shutdown.
Alarm
Shutdown
Overspeed
NOTE:-During the start-up sequence the overspeed trip logic can be configured to allow an extra
trip level margin. This is used to prevent nuisance tripping on start-up - Refer to the 53xx series
configuration software manual under heading ‘Overspeed Overshoot’ for details.
UNDERSPEED, if the engine speed falls below the pre-set trip after the Safety On timer has expired, a shutdown is
initiated. Alarm Shutdown Underspeed will be displayed.
Alarm
Shutdown
Underspeed
GENERATOR HIGH FREQUENCY if the module detects a generator output frequency in excess of the pre-set trip
a shutdown is initiated. Alarm Shutdown High Frequency will be displayed, it is an immediate shutdown.
Alarm
Shutdown
Over frequency
GENERATOR LOW FREQUENCY, if the module detects a generator output frequency below the pre-set trip after
the Safety On timer has expired, a shutdown is initiated. Alarm Shutdown Low Frequency will be displayed.
Alarm
Shutdown
Under frequency
GENERATOR HIGH VOLTAGE if the module detects a generator output voltage in excess of the pre-set trip a
shutdown is initiated. Alarm Shutdown High Volts will be displayed, it is an immediate shutdown.
Alarm
Shutdown
AC Overvolts
GENERATOR LOW VOLTAGE if the module detects a generator output voltage below the below the pre-set trip
after the Safety On timer has expired, a shutdown is initiated. Alarm Shutdown Low Volts will be displayed.
Alarm
Shutdown
AC Undervolts
