DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM 17
OIL PRESSURE SENDER OPEN CIRCUIT, if the module detects a loss of signal from the oil pressure sender
(open circuit) a shutdown is initiated. Alarm Shutdown Sender Fault will be displayed. Sender failure is not delayed,
it is an immediate shutdown.
Alarm
Shutdown
Oil pressure
sender fault
AUXILIARY INPUTS, if an auxiliary input has been configured as a shutdown the appropriate message will be
displayed as configured by the user.
Alarm
Shutdown
Bearing temp high
MAINTENANCE ALARM, will be displayed if the maintenance period is exceeded (engine running hours or date
interval whichever is configured). The engine is shutdown (if configured to do so)
Alarm
Shutdown
Maintenance alarm
LOSS OF SPEED SIGNAL, if the speed sensing signal is lost during cranking, a shutdown is initiated. Alarm
Shutdown Loss Of Speed Signal will be displayed.
Alarm
Shutdown
Loss of speed
signal
NOTE:- This will only occur if the speed sensing signal is lost during cranking or during the safety
on timer. If the signal is lost during normal operation the Generator will shutdown with an Under-speed
alarm.
CAN DATA FAIL If the module is configured for CAN operation and does not detect data on the engine Can
datalink, a shutdown will occur and ‘Can data fail’ is shown on the module’s display.
Alarm
Shutdown
Can data fail
CAN ECU FAIL If the module is configured for CAN instruments and receives a “fail” message from the
engine control unit, the engine is shutdown and ‘Can ECU fail” is shown on the module’s display.
Example
Alarm
The display will alternate
between the text display and the
manufacturers error codes
Alarm
Can ECU fail
Fuel pressure low
Can ECU fail
SPNnnnnnnn
FMInnnnnnn
NOTE:- If the CAN message is a manufacturers specific code, it may not be displayed as text.
If this is the case the display will show the generic manufacturers code, which must be cross-
referenced with the engine manufacturers literature. . Please contact the engine manufacturer for
further assistance.
