Edit Configuration – Advanced – PLC Logic
117
4.15.3 CONFIGURABLE GENCOMM PAGES
For advanced Modbus users of the controller, configurable Gencomm pages are available.
The intention is to allow the user to create personal collections of data in subsequent registers to minimise the
number of modbus reads required by the master, and hence speed up data collection.
The configurable modbus pages are :
Page Hex address Decimal address
166 A600 42496
167 A700 42752
168 A800 43008
169 A900 43264
Example of page configuration
