Edit Configuration - Module
13
4.2.4 DATA LOGGING
NOTE: - Data logging to internal and external memory is available.
The Data Logging page is subdivided into smaller sections.
Select the required section with the mouse.
4.2.4.1 CONFIGURATION
4.2.4.2 OPTIONS
Setting Description
Only log when engine
is running
= The module will log data regardless of engine running state.
= The module will only log data when the engine is running.
Log to USB drive
= The module will log data to the modules internal memory.
= The module will log data to an external USB device connect to the USB host
socket on the module.
Keep oldest data
= When the logging memory is full, the module will overwrite the oldest data first
with the new data.
= When the logging memory is full, the module will stop recording new data.
Select the instrument / item to
be logged. Twenty (20)
selection points are possible.
Select the logging interval
of the data.
To Next Page
