Edit Configuration - Inputs
18
4.4.2 COOLANT TEMPERATURE
4.4.2.1 COOLANT TEMPERATURE ALARMS
Options
Pre alarm
= Pre-alarm is disabled
= If the temperature exceeds the trip setting, an alarm is generated. The temperature
must fall below the return setting to cease the alarm.
Electrical Trip
= Electrical trip is disabled
= If the temperature exceeds the trip setting, an alarm is generated, the load switch is
opened and the module enters the cooling timer after which the set is stopped.
Shutdown If the temperature exceeds the
setting, an alarm is generated, the load switch is opened
and the set is immediately stopped.
Click to edit the
‘sensor curve’. See
section entitled
Editing the sensor
Select the
sensor type
Click and drag to
change the settings
Type the value or click the up and
down arrows to change the settings
Enable or disable
the alarms. The
relevant values
below will appear
greyed out if the
alarm is disabled.
To Next Page
