Edit Configuration - Module
11
4.2.2 CONFIGURABLE STATUS SCREENS
Configurable Status Screens allow the operator to design the status screen to match the requirements of the
end user or application more closely. For instance it is possible to configure the module to show the factory
set ‘summary screen’ and then cycle the display to show instruments specified by the end user. This display
cycling occurs with no user intervention.
This is the page that appears
automatically when the engine is
running (either instrumentation or status)
These instruments are displayed one after the other when
the set runs. If an entry is set to ‘Not Used’, or is not
applicable, the entry is skipped over and not displayed.
To Next Page
