Edit Configuration - Generator
46
4.7.2 GENERATOR VOLTAGE ALARMS
Alarm IEEE designation
Generator Under voltage
IEEE 37.2 - 27AC Under voltage relay
Generator Over voltage
IEEE 37.2 - 59AC Over voltage relay
Click to enable or
disable the alarms.
The relevant values
below appear
greyed out if the
alarm is disabled.
Click and drag to change the
setting.
Type the value
or click the up
and down
arrows to
change the
settings
Click to enable alarm upon
failure tor reach loading
voltage.
Select the type of
alarm required.
For details of these,
see the section
entitled Alarm
Types elsewhere in
this document.
