Edit Configuration - Outputs
38
Output source
Activates… Is not active….
Over Speed Shutdown
IEEE 37.2 – 12 over speed device
Active if the engine speed exceeds the
Over Speed Shutdown
Over Speed Warning
IEEE 37.2 – 12 over speed device
Active if the engine speed exceeds the
Over Speed Warning
Panel locked This output indicates that the module ‘
’ is active. If the Panel lock
input is active, the module will not respond to operation of the Mode select or
start buttons. This allows the module to be placed into a specific mode (such
as Auto) and then secured. The operation of the module is not affected and
the operator will still be able to view the various instrumentation pages etc.
(Front panel configuration access is barred while system lock is active).
Panel lock by digital input This output indicates that a digital input that has been configured as ‘
Lock’ is active. If the Panel lock input is active, the module will not respond to
operation of the Mode select or start buttons. This allows the module to be
placed into a specific mode (such as Auto) and then secured. The operation of
the module is not affected and the operator will still be able to view the various
instrumentation pages etc. (Front panel configuration access is barred while
system lock is active). Refer to the ‘Edit Inputs’ section of this manual for
details.
Panel lock by telemetry This output indicates that remote ‘
’ via telemetry is active. If the
Panel lock is active, the module will not respond to operation of the Mode
select or start buttons. This allows the module to be controller remotely without
local interference. The operation of the module is not affected and the local
operator will still be able to view the various instrumentation pages etc. (Front
panel configuration access is barred while system lock is active).
PLC Output Flag 1-20 A Series of user configured flags that can be used by the PLC to control / drive
internal and external functions
Preheat During Preheat Timer
Becomes active when the preheat timer
begins.
Normally used to control the engine
preheat glow-plugs.
Inactive when :
• The set is stopped
• The preheat timer has expired
Preheat Until End Of Cranking
Becomes active when the preheat timer
begins.
Normally used to control the engine
preheat glow-plugs.
Inactive when :
• The set is stopped
• The set has reached crank
disconnect conditions
Preheat Mode Until End Of Safety
Timer
Becomes active when the preheat timer
begins.
Normally used to control the engine
preheat glow-plugs.
Inactive when :
• The set is stopped
• The set has reached the end of the
safety delay timer
Preheat Mode Until End Of
Warming Timer
Becomes active when the preheat timer
begins.
Normally used to control the engine
preheat glow-plugs.
Inactive when :
• The set is stopped
• The set has reached the end of the
warming timer
Protections Disabled
Indicates the protection system of the module has been disabled by configuration or by
digital input configured to perform this disabling function.
Remote Control 1-10
A series of output sources that can be controlled by remote control in the SCADA
section of the software.
They can be used to control external circuits or can be used in the control logic section
of the configuration suite.
Remote Start In Island Mode This output indicates that a digital input that has been configured as ‘
Start in island mode’ is active. This output could be used to pass the start
signal on to elsewhere in the control system.
Remote Start Off Load
This output indicates that a digital input that has been configured as ‘
Start off load’ is active. This output could be used to pass the remote start
signal on to elsewhere in the control system.
Remote Start On Load This output indicates that a digital input that has been configured as ‘
Start on load’ is active. This output could be used to pass the remote start
signal on to elsewhere in the control system.
