Dell EMC PowerSwitch S4100-ON Series - Features; Physical Dimensions; LED Display

Features
The S4100–ON Series (S4128F-ON, S4148F-ON, S4148FE-ON, S4128T-ON, S4148T-ON, and S4148U-ON) oers the following features:
• S4128F-ON: 28 xed 10GbE SFP+ ports, 2 xed 100GbE QSFP28 ports
• S4148F-ON: 48 xed 10GbE SFP+ ports, 2 xed 40GbE QSFP+ ports, 4 xed 100GbE QSFP28 ports
• S4148FE-ON: 48 xed 10GbE SFP+ ports, 2 xed 40GbE QSFP+ ports, 4 xed 100GbE QSFP28 ports with support for LRM optics
• S4128T-ON: 28 xed copper 10GBase-T RJ-45 ports SFP+ ports, two xed 40GbE QSFP+ ports
• S4148T-ON: 48 xed copper 10GBase-T RJ-45 ports SFP+ ports, two xed 40GbE QSFP+ ports, four 100GbE QSFP28 ports
• S4148U-ON: 24 10G unied Fibre channel and Ethernet SFP+ ports, 24 10G Ethernet SFP+ ports, two 40G Ethernet QSFP+ ports, four
100G unied Fibre channel and Ethernet QSFP28 ports
• One MicroUSB-B serial console management port
• One RJ-45 serial console management port
• One RS-232 serial console port
• One universal serial bus (USB) Type-A port for more le storage
• One 2 Core Rangeley C2338 central processing unit (CPU), with 4GB DDR3 SDRAM and one 16 GB mSATA/M.2 SSD module
• Seven-segment stacking indicator
• Temperature monitoring
• Real time clock (RTC) support
• Hot-plug redundant power supplies
• Removable fans
• Standard 1U chassis
Physical dimensions
The S4100–ON Series (S4128F-ON, S4148F-ON, S4148FE-ON, S4128T-ON, S4148T-ON, and S4148U-ON), has the following physical
dimensions:
• 434 x 460 x 43.5 mm (W x D x H)
• 17.1 x 18.1 x 1.71 inches (W x D x H)
• Power supply unit (PSU) and fan module handle: 1.57 inches (40 mm)
LED display
The S4100–ON Series (S4128F-ON, S4148F-ON, S4148FE-ON, S4128T-ON, S4148T-ON, and S4148U-ON) contains LED displays on the
I/O side and PSU side of the switch.
NOTE
: If you are using third-party software, for more LED information, see their operating software documentation.
12 S4100–ON Series switch
