Dell 2150cn User Manual

48 Installing Optional Accessories
CAUTION: Be careful not to pinch your fingers when lowering the printer onto
the optional 250-sheet feeder.
6 Secure the optional 250-sheet feeder to the printer by tightening the two
screws provided with the feeder, with a coin or similar object.
NOTE: The screw hole is located in 216 mm recess from the front of the
printer.
7 Insert the standard 250-sheet tray into the printer, and push until it stops.
8 Re-connect all cables into the back of the printer, and turn on the printer.
NOTE: The printer will automatically detect the attached tray but will not
detect the paper type.
9 Print the printer settings report to confirm the optional 250-sheet feeder is
installed correctly.

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
