Dell 2355dn User Manual

317
The printer does not appear
on the scanners list.
• Check if your printer is attached to your computer. Ensure that it is connected properly via the
USB port and is turned on.
• Check if the scanner driver for your printer is installed in your system. Open MFP
Configurator, switch to Scanners configuration, then press Drivers. Ensure that driver with a
name corresponding to your
printer 's name is listed in the window.
• Check if the MFP port is not busy. Since functional components of MFP (printer and scanner)
share the same I/O interface (MFP port), the situation of simultaneous access of different
“consumer” application to the same MFP port is possible. To avoid possible conflicts, only
one of them at a time is allowed to gain control over the device. The other “consumer” will
encounter “device busy” response. This can usually happen while starting scan procedure, and
appropriate message box appears.
• To identify the source of the problem, you should open MFP ports configuration and select the
port assigned to your scanner. MFP port's symbol /dev/mfp0 corresponds to LP:0 designation
displayed in the scanners’ options, /dev/mfp1 relates to LP:1 and so on. USB ports start at
/dev/mfp4, so scanner on USB:0 relates to /dev/mfp4 respectively and so forth sequentially. In
the Selected port pane you can see if the port is occupied by some other application. If this is
the case, you should wait for completion of the current job or should press Release port
button, if you are sure that the present port's owner is not functioning properly.
The printer doesn’t scan. • Check if a document is loaded into the printer.
• Check if your machine is connected to the computer. Ensure that if it is connected properly if
I/O error is reported while scanning.
• Check if MFP port is not busy. Since functional components of MFP (printer and scanner)
share the same I/O interface (MFP port), the situation of simultaneous access of different
"consumer" application to the same MFP port is possible. To avoid possible conflicts, only
one of them at a time is allowed to gain control over the device. The other "consumer" will
encounter "device busy" response. This can usually happen while starting scan procedure, and
appropriate message box will be displayed.
To identify the source of the problem, you should open MFP ports configuration and select the
port assigned to your scanner. MFP port's symbol /dev/mfp0 corresponds to LP:0 designation
displayed in the scanners' options, /dev/mfp1 relates to LP:1 and so on. USB ports start at
/dev/mfp4, so scanner on USB:0 relates to /dev/mfp4 respectively and so forth sequentially. In
the Selected port pane you can see if the port is occupied by some other application. If this is
the case, you should wait for completion of the current job or should press Release port
button, if you are sure that the present port's owner is not functioning properly.
I can’t print when I installed
both Linux Print Package
(LPP) and MFP driver on the
same machine
simultaneously.
• Since both Linux Printer Package and MFP driver make a symbolic link to "lpr" printing
command, which is commonly used on Unix clones, it is not recommended to use both
package on the same machine.
Condition Suggested solutions

Dell 2355dn Specifications

General

Current rating	3.5 A
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	465 x 445 x 460 mm
Energy saving mode	Yes
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Printing colors	Black
Maximum duty cycle	80000 pages per month
Recommended duty cycle	1000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	199 copies
Time to first copy (black, normal)	15 s
Copy speed (black, normal quality, A4)	33 cpm
Scan to	E-mail, File, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	8
Input color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	4800 x 4800 DPI
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	10, C5, C6, DL
Maximum print size	210 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 90 g/m²
Display	LCD
Display diagonal	4.3 \
Market positioning	Business
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	-
Supported network protocols (IPv4)	TCP(DHCP, DNS, 9100, LPR, SNMP, HTTP, HTTPS, IPPS, LDAPSIPSec), EtherTalk
Internal memory	256 MB
Maximum internal memory	512 MB
Sound power level (standby)	52 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
Power consumption (off)	0 W
Power consumption (standby)	57 W
Power consumption (PowerSave)	11.36 W
Power consumption (average operating)	502 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	SmartThru Office2 Dell Scan Manager Dell Toner Management System Dell Printer Status Monitor Printer Setting Utility Set IP Address Utility Firmware Upgrade Utility Dell Printer Configuration Web Tool (EWS)
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Certification	ROHS, EN 55022:2006 +A1:2007 / CISPR 22:2005 + A1:2005, EN 61000-3-3; EN55024; FCC CFR Title 47, Part 15 Class B / Part 68; ICES-003, Issue 4, CE GOST, SABS
