47
Scanner Lamp Power Save Mode
The scan lamp under the document glass automatically turns off when it is not in actual use after a
preset period to reduce power consumption and extend the lamp life. The lamp automatically
turns on and the warm-up cycle begins whenever any key is pressed or the DADF cover is opened
or a document is detected in the DADF.
You can set the duration for which the scan lamp waits after a scan job is completed before it
switches to the Power Save mode.
1
Press
Setup
Machine Setup
from the home screen.
2
Press the
Next
( ) button.
3
Press the up/down arrows to select
Initial Setup
.
4
Press the up/down arrows to select
Scan Power Save
.
5
Press the left/right arrows to select the timeout value you want.
6
Press the home icon ( ) to return to the Standby mode.
Changing the Default Mode
You can set the default values for copy, fax, scan, and home window.
1
Press
Setup
Machine Setup
from the home screen.
2
Press the
Next
( ) button.
3
Press the up/down arrows to select
Initial Setup
.
4
Press the up/down arrows to select
Default Mode
.
5
Press the left/right arrows to the function you want to change, and change its settings.
6
Press the home icon ( ) to return to the Standby mode.
Setting the Time Out Option
You can set the time the printer waits before it restores the default copy or fax settings if you do
not start copying or faxing after changing the settings on the operator panel.
1
Press
Setup
Machine Setup
from the home screen.
1
Press the
Next
( ) button.
2
Press the up/down arrows to select
Initial Setup
.
3
Press the up/down arrows to select
Timeout
.
4
Press the left/right arrows to select the timeout value you want.
5
Press the home icon ( ) to return to the Standby mode.

Table of Contents

Other manuals for Dell 2355dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell 2355dn and is the answer not in the manual?

Dell 2355dn Specifications

General IconGeneral
Current rating3.5 A
Fax compatibilityITU-T G3
Dimensions (WxDxH)465 x 445 x 460 mm
Energy saving modeYes
Networking featuresFast Ethernet
All-in-one functionsCopy, Fax, Print, Scan
Color all-in-one functionsScan
Print technologyLaser
Maximum resolution600 x 1200 DPI
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Digital senderNo
Printing colorsBlack
Maximum duty cycle80000 pages per month
Recommended duty cycle1000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6, PostScript 3
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies199 copies
Time to first copy (black, normal)15 s
Copy speed (black, normal quality, A4)33 cpm
Scan toE-mail, File, USB
Scanner typeFlatbed & ADF scanner
Grayscale levels8
Input color depth24 bit
Image formats supportedBMP, JPG, TIF
Maximum scan resolution4800 x 4800 DPI
FaxingMono faxing
Fax memory4 MB
Modem speed33.6 Kbit/s
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity550 sheets
Multi-Purpose tray input capacity50 sheets
Envelopes sizes10, C5, C6, DL
Maximum print size210 x 297 mm
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Multi-purpose tray media typesLetterhead
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 90 g/m²
DisplayLCD
Display diagonal4.3 \
Market positioningBusiness
Standard interfacesEthernet, USB 1.1, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi-
Supported network protocols (IPv4)TCP(DHCP, DNS, 9100, LPR, SNMP, HTTP, HTTPS, IPPS, LDAPSIPSec), EtherTalk
Internal memory256 MB
Maximum internal memory512 MB
Sound power level (standby)52 dB
Sound pressure level (quiet mode)30 dB
AC input voltage220 - 240 V
Power consumption (off)0 W
Power consumption (standby)57 W
Power consumption (PowerSave)11.36 W
Power consumption (average operating)502 W
Mac operating systems supportedMac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled softwareSmartThru Office2 Dell Scan Manager Dell Toner Management System Dell Printer Status Monitor Printer Setting Utility Set IP Address Utility Firmware Upgrade Utility Dell Printer Configuration Web Tool (EWS)
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
CertificationROHS, EN 55022:2006 +A1:2007 / CISPR 22:2005 + A1:2005, EN 61000-3-3; EN55024; FCC CFR Title 47, Part 15 Class B / Part 68; ICES-003, Issue 4, CE GOST, SABS
