Removing the subwoofer
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Remove the wireless card.
3 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
4 Remove the I/O board.
5 Remove the display assembly.
6 Follow the procedure from step 1 to step 7 in “Removing the system board”.
Procedure
1 Remove the screws that secure the subwoofer to the computer base.
2 Lift the subwoofer off the computer base.
45
Removing the subwoofer 102
