Replacing the display-panel
AlienFX LEDs
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Adhere the display-board cables and the display-panel AlienFX LEDs to the
display back-cover.
2 Adhere the mylar that secures the display-board cables and the display-panel
AlienFX LEDs to the display back-cover.
Post-requisites
1 Replace the display panel.
2 Replace the display bezel.
3 Replace the display assembly.
4 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
5 Replace the wireless card.
6 Replace the base panel.
60
Replacing the display-panel AlienFX LEDs 132
