Removing the Alienware
AlienHead LED board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Remove the wireless card.
3 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
4 Remove the display assembly.
5 Remove the display bezel.
6 Remove the display panel.
Procedure
1 Peel off the mylar that secures the display-board cables and the display-panel
AlienFX LEDs to the display back-cover.
2 Disconnect the camera cable from the camera module.
3 Peel off the mylar to access the Alienware AlienHead LED board.
61
Removing the Alienware AlienHead LED board 133
