Replacing the front AlienFX LED
board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Using the alignment posts on the computer base, place the front AlienFX LED
boards on the computer base.
2 Align the screw holes on the front AlienFX LED boards with the screw holes on
the computer base.
3 Replace the screws that secure the front AlienFX LED boards to the computer
base.
4 Connect the front AlienFX LED board cables to the front AlienFX LED boards.
Post-requisites
1 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
2 Replace the base panel.
30
Replacing the front AlienFX LED board 74
