Replacing the I/O board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Align the ports on the I/O board with the slots on the computer base.
2 Align the screw holes on the I/O board with the screw holes on the computer
base.
3 Replace the screws that secure the I/O board to the computer base.
4 Connect the I/O-board cable to the I/O board.
5 Connect the subwoofer cable to the I/O board.
Post-requisites
1 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
2 Replace the base panel.
