Removing the power-button
board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
Procedure
1 Lift the latches and disconnect the touch-pad cable and the status-light cable
from the power-button board.
2 Disconnect the power-button board cable from the power-button board.
3 Remove the screws that secure the power-button board to the palm-rest
assembly.
4 Lift the power-button board off the palm-rest assembly.
13
Removing the power-button board 39
