Replacing the touch pad
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Using the alignment posts on the palm-rest assembly, place the touch pad on
the palm-rest assembly.
2 Slide the touch-pad button cable into the touch-pad button connector and
press down the latch to secure the cable.
3 Align the screw holes on the touch-pad button bracket with the screw holes on
the palm-rest assembly.
4 Replace the screws that secure the touch-pad button bracket to the palm-rest
assembly.
5 Slide the touch-pad cable into the touch-pad connector and press down the
latch to secure the cable.
Post-requisites
1 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
2 Replace the base panel.
20
Replacing the touch pad 54
