Dell Alienware 17 - 64 Replacing the Display Back-Cover; Procedure; Post-Requisites

Replacing the display back-cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
NOTE
: This chapter is applicable only if you have purchased a laptop with non-
touchscreen display.
1 Replace the AlienFX AlienHead board.
2 Replace the AlienFX Display light.
3 Adhere the display-board and camera cable to the display back-cover.
4 Route the display-board cable through the routing guides on the display back-
cover.
5 Connect the camera cable to the camera module.
Post-requisites
1 Replace the Alienware AlienHead LED board.
2 Replace the display-panel AlienFX LEDs.
3 Replace the camera.
4 Replace the display panel.
5 Replace the display bezel.
6 Replace the display assembly.
