Dell Alienware 17 - 51 Removing the Display Hinges; Prerequisites; Procedure

Removing the display hinges
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
NOTE
: This chapter is applicable only if you have purchased a laptop with non-
touchscreen display.
1 Remove the base panel.
2 Remove the wireless card.
3 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
4 Remove the display assembly.
5 Remove the display bezel.
Procedure
1 Remove the screws that secure the hinge caps to the display hinges.
2 Lift the hinge caps off the display hinges.
51
Removing the display hinges 115
