Replacing the Alienware
AlienHead LED board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Connect the camera cable to the camera module.
2 Adhere the Alienware AlienHead LED board and display-board cable to the
display back-cover.
3 Adhere the mylar to secure the Alienware AlienHead LED board and display-
board cable and to the display back-cover.
4 Adhere the mylar to secure the display-board cables and the display-panel
AlienFX LEDs to the display back-cover.
Post-requisites
1 Replace the display panel.
2 Replace the display bezel.
3 Replace the display assembly.
4 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
5 Replace the wireless card.
6 Replace the base panel.
62
Replacing the Alienware AlienHead LED board 136
