Replacing the display assembly
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
Procedure
Post-requisites
Procedure
1 Align the screw holes on the display hinges with the screw holes on the
computer base.
2 Replace the screws that secure the display assembly to the computer base.
3 Route the logo-board cable through the routing guide on the display hinge and
connect the logo-board cable to the system board.
4 Route the display cable through the routing guide on the display hinge.
5 Slide the display cable into the connector on the system board and press down
on the latch to secure the cable.
6 Route the antenna cables through the routing guide on the display hinge and on
the computer base.
7 Connect the antenna cables to the wireless card.
The following table provides the antenna-cable color scheme for the wireless
card supported by your computer.
Connectors on the wireless card Antenna-cable color
Main (white triangle) White
Auxiliary (black triangle) Black
