Replacing the display hinges
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
NOTE
: This chapter is applicable only if you have purchased a laptop with non-
touchscreen display.
1 Align the screw holes on the display hinges with the screw holes on the display
back-cover.
2 Replace the screws that secure the display hinges to the display back-cover.
3 Align the screw holes on the hinge caps with the screw holes on the display
hinges.
4 Replace the screws that secure the hinge caps to the display hinges.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
4 Replace the wireless card.
5 Replace the base panel.
