Replacing the logo board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your computer,
follow the instructions in After working inside your computer. For more
safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1 Adhere the logo board on the display bezel.
2 Connect the logo-board cable to the logo board and adhere the adhesive tape.
3 Slide the display-board cables to their respective connectors on the logo board
and press down the latches to secure the cables.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
4 Replace the wireless card.
5 Replace the base panel.
56
Replacing the logo board 125
